Overview
AVCF13 is a plastic package pressure sensor packaged using high-precision MEMS pressure sensitive chips and mature production processes. The standard pin structure is convenient for customers to use, while providing low-cost plastic sealed pressure sensor solutions for OEM customers. The AVCF13 series plastic sealed pressure sensors are only suitable for dry and non corrosive gases. Different ranges and output methods can be customized according to customer requirements.
Key Features
- Package:SOP6
- Wide Pressure Range:-20°~80°
- Suitable for module assembly
- High Accuracy:±0.3%FS
- Low Cost
- High Reliability
Applications
- Process control system
- Pressure calibration instrument
- Medical instruments
- Environment Monitoring
- Consumer Product
- Sport Product
- Sphygmomanometer
Technical Specifications
| Detection range | 10kPa~100kPa | |
| Pressure Type | Gauge Pressure | |
| Excitation | 5V | |
| Impedance | 4kΩ~6KΩ | |
| Electronic Connection | PINS | |
| Working Temperature | -20°C~80°C | |
| Storage Temperature | -55°C~150°C | |
| Response Time | ≤1ms | Up to90%FS |
| Detection Medium | Dry and non corrosive gas | |
| MechanicalVibration | 20g(20~5000HZ) | |
| Impact | 100g(10ms) | |
| Lifespan | 10×106(Pressure Cycle) |
