Overview
BA-HJS213 turbidity detection module is a universal module with high precision and low range, which reflects the turbidity of the water by detecting the content of suspended solids in the water.
The module adopts analog voltage signal output, which is convenient for users to use and has good selectivity, stability, can meet the user’s detection requirements for a variety of solutions.
Key Features
Low power consumption, high cost performance, wide linear range, convenient calibration and good stability
Applications
It is widely used in the laboratory scientific research, household water purification, washing machine, dishwasher and other fields.
Technical Specifications
| Working voltage | 5V DC | Operating current | 40mA(MAX) |
| Consumption | ≤50mW | Measuring range | 0-1000NTU |
| Size | 38.6×22.1mm | Detection temperature range | 5-90°C |
| Sensor interface | XH2.54 | Output | Analogvoltage |
| linearity | Linear | Response time | ≤500ms |
| Stability time | ≤90s | Service life | 3 years |
