Overview
BA-HJS214 turbidity detection module is a universal module with high precision and high range, which reflects the turbidity of the water by detecting the content of suspended solids in the water.
The module adopts RS485 standard signal output, which has the characteristics of high detection accuracy and good stability, and is widely used in the detection of various low-turbidity water environments.
Key Features
High precision and high range
Applications
It is widely used in the turbidity detection of industrial water use, secondary water supply, water treatment and other scenarios
Technical Specifications
| Power supply | 12-24V DC |
| Power consumption | <0.15W |
| Measure accuracy | ±5% or±3NTU,±3% or±2NTU |
| Measure range | 0-100/0-1000/0-4000NTU |
| Resolution | 1NTU 0.1°C |
| Working temperature | 0-50°C |
| Repetitiveness | ±0.5% |
| Installation | Immersive installation |
| Light source | 860nm |
| Levels of protection | IP68 |
| Output signal | RS485 |
| Response time | ≤1s |
| Working pressure range | 0-0.2Mpa(The water depth is 20m) |
